Steel Plate Blasting and Painting Pretreatment Line

QXY Series Steel Pretreatment Line

QXY series Steel Pretreatment Line is designed and produced by adopting the adv

Skype

产品详情

QXY series Steel Pretreatment Line is designed and produced by adopting the advantages of similar products from both within the country and abroad. The rusting cleaning part (shot blast cleaning) adopts high-effcient blast wheel and full shutter type shot sand separator. The sweeping machine adopts specially made high-strenghth nylon rolling brush and high-pressure ventilator. The preheating and drying part may adopt various heating methods. The paint spraying part adopt high-pressure airless spraying method. The complete set of equipments is contolled by PLC, and is the large-size complete equipment of international advanced.


No.	Type Item		QXY-1600	QXY-2000	QXY2500	QXY3000
1	Steel Plate	With	500-600	1000-2000	1000-2500	1000-3000
		Thickness	3-20	3-60	5-30	3-60
		Length	2000-12000	1500-12000	2000-12000	2400-12000
2	Structural parts	Maximum width	1600	800	2500	1500
		Maximum height	500	300	400	800
		Length	2000-12000	2400-12000	2000-12000	2400-12000
3	Permissible	Permissible	1	1	1.5	2
3	Permissible	Piece transporting speed	2-4	1-5	2-4	0.5-4
4	Total power		450	413.2	550	614
5	Outline dimension(LWH)		7800740062000	62000120007230	6800620054000	55545126557782


Steel Plate Coating Cleaning Line Features

1. Steel descaled by this system can lengthen die life, improve burning, welding and machining operations, and provide the proper surface finish for the application of modern coatings.

2. It is mainly formed by pre-heating part, descaling part, spraying paint part and drying part.

3. The descaling part formed by the cantilever centrifugal type impeller heads, the full shutter type sand separator.

4. The pills cleaning adopted high strength nylon rolls and high pressure blower second level cleaning device.

5. The pre-heating and drying part adopted various heating modes, such as electricity, fuel gas, fuel oil and so on.

6. The spraying paint part adopted the high pressure airless spraying.

7. The full line is centralized controlled by Industrial Personal Computer (IPC).

8. As the shape of steel plate is almost regular before processed, it is helpful for mechanical rust removal and automation of spraying paint, improving the efficiency of dust removing, reducing the intensity of labor and

environment pollution.

9. Mainly used in the field of shipbuilding, locomotive, antiseptic project and bridge construction industries.
